The stack behind every 3AE camera.
Four engineering pillars run end-to-end through the product line — analytics on the edge, image quality you can tune, ANPR built for highway speed, and a security posture your IT team can actually audit.
Seven analytics, on every SKU.
The same AI feature set runs in-camera across the entire 3AE Pro line — no separate AI box, no per-channel license, no spec sheets that quietly drop features on the cheaper SKUs. The recorder sees structured events, not raw motion noise.
- DL People Tracker
- Person-class detection with persistent tracking IDs across the frame
- DL Object Tracker
- Vehicle, bag, and object detection — separate confidence stream
- Intrusion / Tampering
- Zone violation + camera-moved/covered alarms
- Counting / Direction
- Tripwire counts with directional filter; queue analytics
- Tailgating
- Vestibule + access-control double-entry detection
Engineered around Sony Starvis 2.
Every 3AE Pro camera ships with a Sony Starvis 2 sensor and a tuned ISP that survives the scenes most cameras fail at — backlit doorways, sodium-lit car parks, pre-dawn loading bays. Full-color night vision down to 0.03 lux on the day/night SKUs, no IR cut-over flash.
- Sensor
- Sony Starvis 2 — best-in-class low-light + full-pixel readout
- WDR
- 120 dB+ true wide dynamic range, per-region tone mapping
- Noise reduction
- 3D DNR — temporal + spatial, tunable per scene
- Night vision
- TDN with full-color at 0.03 lux on TDN-equipped SKUs
- Codec
- H.265 main / smart streams + H.264 fallback
Read every plate, at highway speed.
Dedicated ANPR housings with adaptive shutter, IR pulse tuned for retro-reflective plates, and a recognition engine trained against international plate formats. The camera publishes a structured event — plate string, confidence, direction, timestamp — over ONVIF the moment a vehicle crosses.
- Capture speed
- Up to 100 km/h at highway-grade lane geometry
- Optics
- Motorised zoom 8–32 mm, dedicated ANPR coating on the glass
- IR strategy
- Pulse-mode IR — retro-reflective plates stay legible at night
- Event format
- ONVIF Profile S structured event, no polling required
- Plate formats
- EU / UK / GCC / SE-Asia / Latin-America trained models
Audit-ready the day it ships.
Surveillance gear is now a network-attached device that IT signs off on. Every 3AE camera ships with 802.1x port authentication, HTTPS-only management, signed firmware, and ONVIF Profile S · G · T compliance for clean VMS integration. Nothing rogue, nothing surprise.
- Port authentication
- 802.1x certificate enrolment when the camera joins the network
- Management plane
- HTTPS on every endpoint — plain HTTP refusable in config
- Firmware
- Signed updates rolled out through the VMS; rollback supported
- Network filters
- IP allow-list, port allow-list, role-scoped user accounts
- ONVIF profiles
- S (streaming) · G (recording) · T (advanced video) — VMS-ready
Drops into the VMS your team already deploys.
We do not ship a proprietary stack. The cameras and recorders speak the protocols your integrators have been wiring for a decade.
- Streaming
- ONVIF Profile S, RTSP, H.265 / H.264 main + sub-streams
- Recording / playback
- ONVIF Profile G, edge SD recording, NVR integration via REST
- Advanced video
- ONVIF Profile T — bidirectional control, smart-event metadata
- Tested with
- Milestone XProtect · Genetec Security Center · DW Spectrum · Network Optix · BluePlanet
- SDK
- C++ + Python SDKs for ANPR event ingestion and tracker metadata streams
- Certifications
- CE · FCC · RoHS · ONVIF conformance · IK10 / IP67 housing where rated
Hand us the integration spec.
VMS, access control, BI dashboard, tolling platform — we have wired most of them before. Send the brief and we will return SDK access, sample events, and an engineering contact inside one business day.
